Piping Support Fabrication Drawing Generation Tool 'ASPO Support Fab'
Automatic generation of piping support fabrication drawings from 3D models.
This is an add-in that automatically generates DWG files for pipe support production directly from model information in Autodesk AutoCAD Plant 3D. It reduces the need for re-entering data into 2D CAD or creating BOMs in Excel, connecting the design data directly to the manufacturing process. *For more details, please download the PDF or feel free to contact us.*
basic information
Autodesk AutoCAD Plant 3D add-in. Directly generates production DWG from the model, supporting shoes, clamp shoes, guides, stoppers, trunnions, pads, and U-bolts. It also supports reflecting custom supports in ISO drawings and maintaining SSOT through synchronization between the model and drawings, adapting to design changes. *For more details, please download the PDF or feel free to contact us.
Price information
For more details, please contact us.
Delivery Time
Model number/Brand name
ASPO Support Fab
Applications/Examples of results
Utilized for creating fabrication drawings for plant piping support. The drawing time, which used to take about 30 minutes per sheet, has been reduced to approximately 5 minutes, achieving a reduction of about 83%. For a project with around 1,000 sheets, we anticipate a reduction effect of about 417 hours and approximately 1.25 million yen. It also contributes to reducing human errors, standardizing drawing quality, and ensuring traceability. *According to our research. *For more details, please download the PDF or feel free to contact us.
