Electric Shut-off Gate for Hygiene Maintenance and Wastewater Conservation in Food and Beverage Factories
A sluice gate that automatically detects abnormal values in food and beverage wastewater using pH meters, oil film detectors, turbidity meters, etc., and closes the drainage channel. It achieves hygiene management and environmental conservation through high water stop performance.
In semiconductor and electronic component factories, acidic and alkaline wastewater is handled, and even a small amount of leakage can have a significant environmental impact. This equipment automatically closes the gate when it detects abnormalities such as pH or oil films. With high sealing performance, it seals the drainage channel. Custom designs are possible to accommodate complex drainage lines such as cleanroom wastewater and process-specific wastewater. It is a highly reliable system that contributes to both environmental conservation and equipment protection. 【Features】 - Response to abnormalities in acid and alkaline wastewater - Optimal design for each chemical line - Automatic control to reduce environmental risks - Numerous implementation examples in the semiconductor industry *We also offer a diverse lineup of sluice gates tailored to various applications! For more details, please refer to the catalog or feel free to contact us.
basic information
【Specifications】 ■ Type: Stainless steel or steel sluice gate ■ Opening dimensions: 100×100 to 2000×2000mm ■ Design water depth: Designed as per request ■ Operating water depth: Designed as per request ■ Water-tight method: Three-way or four-way rubber water-tight type ・Can stop water even at low water pressure using a tapered block ■ Opening and closing mechanism: Electric (rack type or spindle type) ■ Control method: Designed as per request ・Interlock with pH meter, oil level meter, rain gauge, etc. for blocking operation via sensor signals ・Control via remote operation ・Manual operation on-site, etc. ■ Blocking time: 300mm/min (standard) 【Kanae Interesting Course】⇒ https://www.kanae.co.jp/about/gate.html ⇒ 'Technology for Preventing the Discharge of Harmful Substances' *For more details, please refer to the catalog or feel free to contact us. (Kanae: Sluice gate manufacturer)
Price information
Please contact us.
Delivery Time
Applications/Examples of results
For more details, please refer to the catalog or feel free to contact us.
