Dynamic Resin Strong Guard TNK Method
Flame-retardant epoxy resin-based adhesive can be used to ensure flame resistance, self-extinguishing properties, and safety of generated gases!
The "Dynamic Resin Strong Guard TNK Method" is a construction method designed to prevent spalling in tunnels (small piece spalling prevention) and bridge concrete spalling. The applicable temperature range for spalling prevention performance is -30 to +50°C (suitable for cold regions). By using a special continuous fiber sheet, it maintains high push-out performance. Additionally, by using a flame-retardant epoxy resin-based adhesive, it ensures fire resistance, self-extinguishing properties, and safety of generated gases. 【Features】 ■ Applicable for spalling prevention in tunnels (small piece spalling prevention) and bridge concrete. ■ Spalling prevention performance applicable temperature range: -30 to +50°C (suitable for cold regions). ■ High push-out performance can be maintained by using a special continuous fiber sheet. ■ Weather-resistant inorganic paint is adopted for the finishing coat. *For more details, please download the PDF or feel free to contact us.
basic information
【Engineering】 ■ Substrate treatment worker ■ Primer application worker ■ Fiber sheet adhesive worker (adhesive primer) ■ Fiber sheet adhesive worker (fiber sheet application) ■ Fiber sheet adhesive worker (adhesive topcoat) ■ Finishing material application worker *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Purpose】 ■ Measures to prevent the falling of small pieces of reinforced concrete in the tunnel's inner space, at the portal area, and in sections with low soil cover. ■ Measures to prevent the falling of small pieces of unreinforced concrete in the general sections of the tunnel. ■ Measures to prevent the falling of concrete pieces from bridges. *For more details, please download the PDF or feel free to contact us.
