Salt Damage Prevention Corn "Protect P Con"
Reusable as an insert during repair work! Ceramic inserts with excellent vibration absorption properties.
"Protech P Con" is a corrosion-resistant insert that can be reused by replacing the fixed nut of the SC with a hole-punched insert (PI-35-12). It features the ability to absorb vibrations from rod vibrators and the bending stress of sleeves caused by the weight of fresh concrete and round spacers. All performance tests comply with the "Insert Design and Construction Manual (Draft)" published in April 2005 by the Japan Prestressed Concrete Institute (PC Kenkyu). 【Features】 ■ Reusable as an insert during repair work ■ Vibration absorption from rod vibrators ■ Absorption of bending stress in sleeves caused by the weight of fresh concrete and round spacers (long lengths) *For more details, please download the PDF or feel free to contact us.
basic information
【Specifications】 ■Material: Ceramics + Stainless Steel (SUS (non-magnetic treatment)) ■Steel used: SUS (non-magnetic treatment) ■Covering technical standards: Japan Society of Civil Engineers "Standard Specifications for Concrete" (2007) / Architectural Institute of Japan "Reinforced Concrete Structural Design Standards" (2010) ■Screw sizes: W 5/16, W 3/8, W 1/2, W 5/8, M12, M16 *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Applications】 ■ Large concrete structures ■ Permanent structures ■ Corrosive environments ■ Pre-tensioned factory products *For more details, please download the PDF or feel free to contact us.
catalog（1）
Download All Catalogs
Distributors
Masuyama Co., Ltd. is a company that handles products related to bridges, including formwork materials, temporary materials, safety materials, insulation materials, and other leasing-related items. We sell original products such as "Tension Protectors" and "Ashibal" [Image Up Pipes], and we ship not only domestically but also overseas. We will continue to grow with an eye on expanding internationally.
