AutoCAD Plant3D add-on software 'ASTO'
Designing piping supports quickly and efficiently!
"ASTO" is an add-on (function extension) software for "AutoCAD Plant 3D" that allows for the free design of 3D piping supports. Using ASTO's unique interface, you can place pre-prepared piping support models without the need to create support parts from scratch. In addition to automatically outputting the piping supports (3D) placed within the 3D model to production drawings (2D), it is also possible to automatically aggregate and compile a list of the materials used in the 3D model, preventing ordering mistakes due to counting errors. 【Features】 ■ Designing "piping supports" is surprisingly easy ■ Convert piping support 3D models to 2D production drawings in 10 seconds ■ Instantly compile a list of used materials with the automatic aggregation feature ■ Tables can be used in Excel *For more details, please download the PDF or feel free to contact us.
basic information
【Our Strengths】 ■ Development of software that can be practically utilized in collaboration with the design department ■ Development of software incorporating know-how accumulated over many years ■ Release of version upgrades that meet customer needs *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Applications/Examples of Achievements】 ■Improvement of design efficiency through the library of piping supports and parametric drawing ■Reduction of drawing man-hours through automation of 2D drawing creation based on 3D models ■Increased design efficiency with registered support models ■Output of a large number of drawings in a short time *For more details, please download the PDF or feel free to contact us.
