Many Olympic athletes produced! 【Sagamihara Gion Urban Sports Park】
Supervised by the Japan Skate Park Association! Focus on a park layout that everyone can enjoy!
Koyama Park New Sports Square, which has produced athletes such as Shirai Sora, Fujisawa Niko, and Yoshizawa Ren. A large-scale park of approximately 2,000m2, supervised by the Japan Skate Park Association. Designed as a "park that everyone can enjoy," it features a meticulously crafted layout. It includes unique elements not found in traditional parks, such as a "manual pad" made entirely of granite and the replication of pool coping shapes in granite. The park offers a well-equipped environment with a "street area" for advanced practitioners to practice, a "street area" that beginners can also enjoy, and an attractive "bowl area," making it a place where both advanced and beginner skaters can have fun. During the opening ceremony, many users participated, making it a resounding success on its first day.
basic information
The "Seal Hard Skate Park Specification" is a construction method product provided through the following steps 1 to 4. [Patent pending] ◆1. Concrete Grinding (Renovation only) The roughened concrete surface is shaved down to remove surface irregularities. ◆2. Concrete Polishing For newly laid concrete: Smooth out trowel marks, trowel lines, and fine irregularities on the surface to create a smooth surface without roughness. For renovated concrete: Further smooth out grinding marks and fine irregularities from the surface that has been leveled in the previous step to create a smooth surface without roughness. ◆3. Penetrating Surface Hardener Seal Hard This is a concrete surface hardener that "penetrates" rather than "coats." It provides strong dust resistance and wear resistance to the concrete. Since it does not create a film on the concrete surface but densifies and strengthens the internal layers, it results in a concrete floor finish that is free from peeling. ◆4. Water Absorption Suppressor (Water Repellent) Aquapel Plus This is a concrete surface water absorption suppressor (water repellent) that "penetrates" rather than "coats." It does not create a film on the concrete surface but imparts water-repellent properties to the internal layers, allowing it to maintain water absorption suppression effects for a long time if the surface does not wear down.
Price information
The price varies depending on the construction area and the roughness of the surface. For more details, please contact us.
Delivery Time
Model number/Brand name
Seal Hard Skate Park Specification
Applications/Examples of results
"Skate Park Achievements" - Nagao Skate Park (Sanuki City, Kagawa Prefecture) - Sumida Skateboard Park (Sumida Ward, Tokyo) - AKAKEN PARK (Kanazawa City, Ishikawa Prefecture) - NiX Urban Sports Park (Toyama City, Toyama Prefecture) - Green Park Daimon Skateboard Square (Imizu City, Toyama Prefecture) - Toyo Carbon Urban Sports Park (Marugame City, Kagawa Prefecture) - Ibaraki Electric Construction Skateboard Park Ishioka (Ishioka City, Ibaraki Prefecture) - Chausuyama Skate Park (Nagano City, Nagano Prefecture) - Gruun Gamagori Skate Park (Gamagori City, Aichi Prefecture) - Skate Park within the Miyoshi Town Hall Grounds (Miyoshi Town, Saitama Prefecture) - Musashino Park Skateboard Square (Fuchu City, Tokyo) - Wakamiya Oodori Park Skate Park (Nagoya City, Aichi Prefecture) - Oku Biwa Sports Forest Skateboard Park (Nagahama City, Shiga Prefecture) - Skate Park Oobu (Oobu City, Aichi Prefecture) - Osawa Comprehensive Ground Skateboard Area (Mitaka City, Tokyo) - Awaji City Skateboard Park (Awaji City, Hyogo Prefecture) - Hinai-gata Park Skateboard Park (Kyoto City, Kyoto Prefecture) Others / 4 cases
Detailed information
-
Surface Grinding A diamond blade is mounted on a large grinding machine to remove the weak surface layer in advance and achieve a smooth finish.
-
【Seal Hard Application】 We will apply the penetrating concrete surface hardener "Seal Hard." With the effect of Seal Hard, the concrete surface will gradually harden and transform. Since Seal Hard is a penetrating type and not a film-forming type, it will not peel off. However, penetrating hardeners are vulnerable to rainwater, and when exposed to rain, the penetrating components can dissolve and wash away.
-
Cleaning
-
【Application of Aquapel Plus】 The penetrating water-repellent agent "Aquapel Plus" will be applied. By applying Aquapel Plus, we compensate for the weaknesses of seal hard that are vulnerable to rain, transforming it into a strong, rain-resistant concrete. Since it is a non-film-forming penetrating type, it will not peel off.
-
[Test Run Confirmation] If Aqua Pearl Plus is applied too much, the grip feeling weakens and it may skid during turns. Therefore, a staff member skilled in skateboarding will actually test run on a skateboard to check the resistance during sliding and the grip feeling during turns. If any issues are found during the confirmation, adjustments will be made through re-cleaning with a polisher or polishing.
catalog（7）
Download All Catalogs
CAD data（1）
| Model number | overview | File |
|---|---|---|
| Standard Drawing for Skate Park Surface Specifications | The "Seal Hard Skate Park Specification" is a construction method provided in the following steps 1 to 4. [Patent pending] ◆1. Concrete grinding (for renovation only) ◆2. Concrete polishing ◆3. Penetrating surface hardener Seal Hard ◆4. Water absorption suppressor (water repellent) Aquapel Plus This is a pavement specification created based on past achievements. Please feel free to copy and use it when designing future skate parks. |
|
